Produktbeskrivning

PowerWalker VFD 600 (CEE 7/3)

Art-nr: 10120401
EAN: 4260074970562

Surge protection on phone line and modem
Type F (CEE 7/3) sockets
Highly compact and lightweight

PowerWalker VFD 600-1000 CEE 7/3 Series is a standby/offline UPS which provides secure protection and reliable and cost-effective backup power. The UPS can be automatically started up without AC power supplied. In addition, this UPS provides RJ11/RJ45 surge protection, and green power function for energy saving. Its pro-active audible warning reminds you the abnormal condition and ensures your connected equipment. This UPS provides clean and stable power protection to connected equipment and is perfect for home and small office application.

Type F

600VA

1000VA

Allmänna funktioner
Typ	Offline
Energikapacitet	600VA / 300W
Utgående energifaktor	0.50
Input
Ingående spänningsområde	170-280 VAC
Frequency (Synchronized Range)	50Hz or 60Hz
Output
Nominell utgående spänning	230 VAC
Spänningsreglering	±10%
Frequency (Battery Mode)	±1Hz
Tekniska detaljer
Transfer Time [AC to Battery]	2-6ms
Overload Capacity	N/A
LED Indicators	AC Mode: Green LED Battery Mode: Green LED flashing (4sec interval) Low Battery: Green LED flashing (1sec interval) Fault: RED LED Battery weak: RED LED flashing (2sec interval) Battery faulty: RED LED flashing (3x interval)
Effektivitet
LINE mode full Load	99.0%
Batterier och autonom tid
Batterier	1x 12V/7Ah
DC Voltage	1 x 12V
Recharge Time	10h to 90%
Full Load Backup Time	1min
Half Load Backup Time	7.5min
Anslutningar och kommunikation
CEE 7/3 (Type F) Outlet	2
Input	CEE 7/7
RJ-45/RJ-11 protection	Ja
Miljö
Bullernivå	No Fan
Temperatur	0°C – 40°C
Fuktighet	0% - 90% RH (non-condensing)
Logistik
Package Content	UPS, Manual
Manual Languages	EN/DE/FR/ES/IT/PT/SE/FI/NO/TR/RU/UA/BY/PL/CZ/HR/HU/BG/KZ/SR
EAN	4260074970562
Bredd	81 mm
Vikt	185 mm
Djup	231 mm
Vikt	3.8 kg
Giftbox - Bredd	126 mm
Giftbox - Vikt	224 mm
Giftbox - Djup	285 mm
Giftbox - Vikt	3.8 kg
Carton - Bredd	580 mm
Carton - Vikt	402 mm
Carton - Djup	250 mm
Carton - Vikt	11.5 kg
Pcs. per box	6
Pcs. per layer	24
Pcs. per pal	192
